Pneumatic Knife Edge Gate Valve

10000.00 - 100000.00 INR/Piece

Get a Price/Quote

Product Details:

Type Knife Edge Gate Valve
Material Stainless Steel
Media Water
Working Presssure High Pressure
Click to View more
Share Your Product:

Request to Call Back Send Inquiry

Price And Quantity

Minimum Order Quantity 1 Piece
Price Range 10000.00 - 100000.00 INR/Piece

Product Specifications

Working Presssure High Pressure
Type Knife Edge Gate Valve
Media Water
Material Stainless Steel

Trade Information

Supply Ability 1 Piece Per Day
Delivery Time 1 Week
Main Domestic Market All India

Product Description

This Pneumatic Knife Edge Gate Valve blends cutting-edge technology with sturdy construction to enhance performance and dependability. The Pneumatic Knife Edge Gate Valve was painstakingly designed with a knife-like gate that glides into place and creates an airtight seal to control the flow of diverse media, from fluids to powders. With this special gate design, there will be less pressure loss, increasing efficiency and consuming less energy.

Applications:

Industries handling bulk products like powders, grains, and pellets use this pneumatic knife edge gate valve.
This valve is essential to mining operations because it allows for the regulated outflow of tailings, ores, and minerals.
The Pneumatic Knife Edge Gate Valve helps thermal power plants manage the flow of ash, slag, and other combustion byproducts from boilers.
The valve's construction makes it suited for situations with corrosive chemicals and allows for precise control during procedures like mixing, blending, and transferring chemicals.

Pneumatic Knife Edge Gate Valve is similar to gate valves in design and is originally designed for usage in the pulp and paper industries. It can cut through thick, porous medium that may include a high concentration of suspended particulates, which previously created difficulties with valves not seating entirely and so leaking. It is very economical to use. This soft sealing surface is often used in low-pressure systems and is not designed to withstand high pressure. This valve is intended for isolation rather than throttled or partial-flow applications.

Here are some key features and aspects of a Pneumatic Knife Edge Gate Valve:

1. Gate Design: The gate of this type of valve has a sharp edge that can cut through the fluid, ensuring minimal pressure drop when the valve is fully open and a tight seal when closed. This design is especially suitable for applications with abrasive, viscous, or slurry-like fluids.

2. Bidirectional Flow: Knife edge gate valves are usually designed to allow bidirectional flow, meaning they can control the flow of fluids in both directions.

3. Actuation: Pneumatic actuation involves the use of compressed air or gas to open and close the valve. This type of actuation allows for precise and automated control, making it suitable for industrial processes that require remote or continuous operation.

4. Applications: Pneumatic knife edge gate valves are commonly used in industries where reliable shut-off and flow control are essential, such as in mining, chemical processing, power generation, pulp and paper manufacturing, wastewater treatment, and more.

5. Abrasion Resistance: These valves are well-suited for handling abrasive materials like slurries, powders, and granular substances. The knife-edge gate design helps to prevent material buildup that could hinder the valve's functionality.

6. Isolation: Knife edge gate valves are excellent for isolation applications where a tight shut-off is necessary to prevent leakage or contamination.

7. Low Maintenance: The design of these valves, particularly their ability to prevent material buildup, contributes to lower maintenance requirements compared to other types of valves in similar applications.

8. Materials of Construction: Pneumatic knife edge gate valves are available in various materials of construction to suit different applications and fluid types. Common materials include stainless steel, cast iron, carbon steel, and various corrosion-resistant alloys.

9. Accessories: These valves can be equipped with various accessories such as positioners, limit switches, and solenoid valves to enhance their performance and integration into automated systems.
