Pneumatic Angle Type Control Valve

3500 INR/Piece

Get a Price/Quote

Product Details:

Click to View more
Share Your Product:

Request to Call Back Send Inquiry

Pneumatic Angle Type Control Valve Price And Quantity

Price 3500 INR/Piece
Minimum Order Quantity 1 Piece

Pneumatic Angle Type Control Valve Trade Information

Supply Ability 1 Piece Per Day
Delivery Time 1 Days

Product Description

We are offering industrial grade Pneumatic Angle Type Control Valve which is especially designed for the medium to high pressure flow systems to control the fluid flowing rate within the different branches of the flow systems. It is machined with advanced technologies which gives excellent finish to the inner as well as outer surfaces of this fitting. This valve is also provided with an anti-corrosive which gives excellent protection against acidic, neutral and alkaline liquids.

Pneumatic Angel Type Control Valve Specifications:

1. Material: SS304

2. Body Style: Y Type

3. Connection Type: Screwed, Flanged, Tri Clover

4. Size: 15 mm--100 mm

5. MOC: SS304

6. Working Pressure: PN16

7. End connection: Screwed, Flanged

8. Media: AIR / STEAM / GAS /WATER / OIL / CHEMICAL

9. Pneumatic Pressure: 3.5 to 7 BAR

FAQ:

Q: What is a pneumatic angle type control valve?

A: A pneumatic angle type control valve is a type of control valve used to regulate the flow of fluids (liquids or gases) in industrial processes. It's called "angle" because the valve body is designed at an angle, usually 90 degrees. This design helps to minimize pressure drop and turbulence in the flow, making it suitable for applications where flow control and pressure drop reduction are important.

Q: How does a pneumatic angle type control valve work?

A: The valve operates by using pneumatic pressure to control the position of the valve's internal mechanism, typically a throttling element like a plug or a ball. When the control system sends a signal, the pneumatic actuator adjusts the position of the throttling element, thereby regulating the flow of fluid through the valve.

Q: What are the advantages of using pneumatic angle type control valves?

A: Pneumatic angle type control valves offer several advantages, including fast response times, reliability, and suitability for high-pressure applications. They are also less sensitive to environmental conditions compared to electronic control systems. Additionally, the angle design helps to reduce pressure drop and the risk of cavitation, making them ideal for applications with varying flow rates.

Q: What are some typical applications for pneumatic angle type control valves?

A: These valves are commonly used in industries such as oil and gas, chemical processing, power generation, water treatment, and more. They are suitable for controlling the flow of various fluids in processes that require precise regulation to maintain desired conditions such as pressure, temperature, or flow rate.

Q: How is the pneumatic actuator controlled?

A: The pneumatic actuator of the valve is controlled by a pneumatic control system. This system includes instruments like pressure regulators, positioners, and controllers. The control system receives signals from sensors that monitor process conditions, and based on these signals, it adjusts the position of the actuator to control the valve's opening and closing.

Q: What maintenance do pneumatic angle type control valves require?

A: Regular maintenance is essential to ensure the optimal performance of pneumatic angle type control valves. This includes checking for air leaks, cleaning or replacing filters, lubricating moving parts, and calibrating the control system. Proper maintenance helps extend the valve's lifespan and ensures accurate control.
